What does a 200-amp electrical panel upgrade cost in Markham?
$6,910.00
$1,650.00
For this Markham 200A service and panel upgrade, RenoFiz estimated about $6,910 CAD for the mandatory scope, plus up to $1,650 CAD of possible extra work for wall repair or AFCI-breaker upgrades if the site calls for it.
Is this like your project?
Location
Markham, ON
Service size
Upgrade to 200 amps
Service type
Overhead mast and exterior meter base
Panel location
Inside the garage
Utility
Alectra
Exterior siding
Vinyl
Wire run
Approximately 10 ft, meter to panel
Where the $6,910 project cost goes
Where the $6,910 project cost goes
See the full cost breakdown for this project.
| Scope item | Labour | Materials | Total |
|---|---|---|---|
| Utility Coordination & Scheduling | $266.00 | — | $266.00 |
| Service Demolition | $399.00 | — | $399.00 |
| 200A Service Mast & Meter Base | $798.00 | $950.00 | $1,748.00 |
| Main Panel Demolition | $266.00 | — | $266.00 |
| 200A Main Panel Installation | $1,330.00 | $1,225.00 | $2,555.00 |
| Service Entrance Conductors | $266.00 | $250.00 | $516.00 |
| Grounding & Bonding System | $399.00 | $375.00 | $774.00 |
| Permit & Inspection Coordination | $266.00 | $120.00 | $386.00 |
| Complete base project cost | $3,990.00 | $2,920.00 | $6,910.00 |
Total Cost
$6,910.00
Possible extra
$1,650.00
On-site decisions or hidden conditions that could increase the scope.Want an estimate for your project?
Chat with Chris, RenoFiz's AI project assistant. Chris will build a scope, show what could change the price, and connect you with the right pro.
Things to know for your project
Things to know for your project
Conditions, constraints, and on-site decisions that shape the final project cost.
Water damage behind the siding
Trigger: Rotten wall sheathing or framing is discovered behind the vinyl siding when the existing mast is removed.
A general contractor would need to repair the sheathing or framing. This example identifies approximately $450 in possible additional wall repair work.
Inspector-mandated AFCI breakers
Trigger: The inspector requires AFCI (arc-fault circuit interrupter) breakers on existing branch circuits during the panel replacement.
The electrician would install AFCI breakers to bring existing circuits up to current code. This example identifies approximately $1,200 in possible additional work.
Different site conditions or Alectra Utilities requirements
Trigger: A contractor confirms site conditions and Alectra Utilities' specific requirements for the property differ from what was described.
The final cost may shift once a contractor confirms site conditions and Alectra Utilities' specific requirements. This example does not assign a price to that unknown.
The real conversation behind this estimate
The real conversation behind this estimate
This is the how RenoFiz gathered the facts and turned a simple request into a scoped estimate.
Hi there — I'd like a service upgrade. Overhead power lines attach at the corner of my house and drop down in a pipe to the meter base on the front corner, and my panel is inside the garage. So I'll need:
- new lines pulled from Alectra Utilities
- a new overhead connection with a pipe down to a new meter base
- and a new 200 amp panel inside the house
That's a standard 200-amp service upgrade. With Alectra Utilities, there are specific mast-height and meter-base requirements an electrician will need to verify.
A few questions to price it accurately:
Question: What's your postal code (just the first three characters, e.g., L3R)?
Question: Roughly how far is the wire run from the outdoor meter base to the indoor panel?
Question: What's the exterior siding where the new mast and meter will mount?
- Stucco
- Wood Siding
- Vinyl Siding
- Brick/ Stone
- Fiber Cement (Hardie)
Photos that would help If you can, please share:
- The current overhead service mast and where the wires attach.
- The meter base on the exterior.
- The electrical panel in the garage (door open so I can see the breakers).
- The path or wall between the meter and the panel.
What's your postal code (just the first three characters, e.g., L3R)?: L3R
Roughly how far is the wire run from the outdoor meter base to the indoor panel?: 10ft
What's the exterior siding where the new mast and meter will mount?: Vinyl Siding
Thanks — that's everything I need to put together your estimate for the 200-amp service upgrade in Markham.
Photos that would help Before I finalize, a few photos would confirm the exact mounting for your vinyl siding and the garage panel layout:
- The overhead service mast and where the wires attach.
- The meter base on the vinyl siding.
- The electrical panel in the garage (door open).
- The wall area between the meter and the panel.
If you can't grab photos right now, no problem — I'll proceed with what you've given me. Want me to generate the estimate now?
Sorry, I don't have pictures right now.
Here's your estimate for the 200-amp service upgrade in Markham.
Work Summary
This project upgrades the home's electrical service to 200 amps for modern power demands. It covers swapping the exterior overhead mast and meter base, fitting a new 200A main breaker panel in the garage, and updating the grounding to current safety codes. All Alectra Utilities coordination and required electrical inspections are included.
Cost Estimate
| Description | Labour | Material | Total |
|---|---|---|---|
| Utility Coordination & Scheduling<br>Coordinate the service disconnect and reconnection with Alectra Utilities. | $266 | $0 | $266 |
| Service Demolition<br>Remove the existing overhead mast, meter base, and old conductors. | $399 | $0 | $399 |
| 200A Service Mast & Meter Base<br>New overhead mast and meter base; seal the vinyl-siding penetrations. | $798 | $950 | $1,748 |
| Main Panel Demolition<br>Remove the existing panel from the garage wall. | $266 | $0 | $266 |
| 200A Main Panel Installation<br>New 200A main breaker panel; transfer the existing circuits. | $1,330 | $1,225 | $2,555 |
| Service Entrance Conductors<br>New 200A service wire from the meter base to the main panel (10 ft). | $266 | $250 | $516 |
| Grounding & Bonding System<br>New ground rods/plates and copper conductor to meet Ontario Code. | $399 | $375 | $774 |
| Permit & Inspection Coordination<br>Coordinate the inspection and carry the permit-fee allowance. | $266 | $120 | $386 |
Cost Summary
| Category | Amount |
|---|---|
| Materials | $2,920 |
| Labour | $3,990 |
| Mandatory Scope Total | $6,910 |
Potential Additional Items
| Description | Trade | Est. Cost | On-Site Trigger |
|---|---|---|---|
| Wall Repair<br>Repair rotten sheathing or framing behind the vinyl siding. | GC | $450 | Water damage found when the mast comes off. |
| AFCI Breaker Upgrades<br>Fit AFCI breakers on existing circuits if the inspector requires it. | Electrician | $1,200 | Inspector mandate during the panel swap. |
Note: final pricing may shift once a contractor confirms site conditions and Alectra Utilities' specific requirements for your property.
The Request a Pro button is now active — tap it to connect with a local contractor for an on-site visit and firm quote.
